Tändmodul Compu-Fire elektronisk förtändning enkeltändning Big Twin 70-99
Compu-Fire tändmodul med elektronisk tändförställning och single fire
Läs mer
- Endast för modeller med elstart
- Fast single fire samt valbar enkel eller dubbel tändstiftskonfiguration
- Justerbar tändförställning och varvtalsbegränsare
- 8 tändkurvor och 8 varvtalsgränser från 6000 upp till 7500 RPM
- Enkel inställning via vridreglage på tändningsenheten
- Inbyggd lampa för statisk tändinställning
- Förlängt temperaturområde, funktion vid låg spänning och mjukstartskrets för enkel start
Varvräknaradapter (MCS 538408) krävs vid användning av single fire-tändning för att varvräknaren ska visa korrekt varvtal.
Passar: Big Twin 70-99
| Kategori | Ignitions |
| Produkt-typ | Ignitions |
Ignition module. Electronic advance, single fire
- For electric start models only
- Fixed single fire and selectable single/dual plug
- Selectable advance & RPM limiter
- With 8 advance curves and 8 RPM limits, from 6000 up to 7500 RPM, it can be adjusted to fit your specific engine
- Easy selection by a rotary switch on the ignition unit
- Module comes with a built-in static timing light and feature a extended temperature and low voltage operation with soft-start circuitry for easy starting
- Note: A tach adapter (MCS 538408) is required to correct tacho-output when using single fire ignition, for correct RPM representation
Fits: 70-99 Big Twin (Excl. Twin Cam, Excl. injection models); 71-01 Sportster (Excl. 1200S) (NU)
