Modul blinkers Custom Dynamics Smart TSM3 Softail 07-10

4 750 kr

Blinkersmodul TSM3 med automatisk avstängning från Custom Dynamics
Läs mer

20500555 Custom Dynamics
  • Direkt plug-and-play-ersättning för original TSM, TSSM och HFSM
  • Fungerar enbart som TSM (ersätter inte fabrikslarmets funktioner)
  • Kompatibel med både LED och glödlampor (0,24 A–6 A maximal belastning per sida)
  • Kräver ingen lastutjämnare blinkers vid konvertering till LED
  • Både manuell och automatisk avstängning baserat på tid och nedläggningsvinkel
  • Automatisk avstängning om motorcykeln lutar mer än 45° åt höger eller vänster i 1 sekund eller längre
  • Full funktion för varningsblinkers baserat på tid, tändningsläge och batterispänning
  • Integreras med originalets säkerhetsbrytare för att förhindra start med växel i utan kopplingen indragen
  • Låg strömförbrukning samt inbyggt kortslutnings- och överbelastningsskydd
  • Driftspänning: 11 VDC till 15 VDC
  • Förenklad parkopplingsprocedur för utvalda modeller, kompatibel med mjukvara från CanDo och Technoresearch

Monteringsanvisning ingår. Tätning till originalkontaktens anslutning finns tillgänglig separat (artikelnr 709107).

Passar: H-D 07-17

OEM-nr: 68921-07, 68925-07, 69976-08

Turn Signal Module

  • Direct OEM TSM, TSSM, and HFSM Plug-and-Play replacement on Harley-Davidson models. Functions as TSM only, no security functions
  • Compatible with LED or incandescent bulbs (0.24 A-6 A maximum turn signal load per side), eliminating the need for a load equalizer or signal stabilizer when converting to Custom Dynamics’ LED turn signals
  • Simplified marrying procedure for select models and compatible with CanDo and Technoresearch software
  • Offers both manual and self-canceling turn signal cancelation functions based on timing and bank angle of the motorcycle; along with full operation of four-way hazards
  • Provides automatic shut off parameters when vehicle tilt exceeds 45° right or left for 1 second or more.
  • Low current consumption with built-in short circuit & over circuit protection
  • Wide operating voltage: 11 VDC to 15 VDC
  • Smart turn signal module TSM3
  • This will replace OEM TSM (Turn Signal Module) 68921-07, HFSM (Hands Free Security Module) 68925-07 (for US & HDI/EU models) and HFSM 69976-08
  • It will not replace the HFSM factory alarm features
  • Installation instructions are included
  • Lighting Compatibility: Works with both LED and incandescent bulbs
  • Turn Signal Load Range: Supports 0.24A to 6A per side
  • No Load Equalizer Required: Compatible with BCM-compliant LED upgrades
  • Four-Way Hazard Operation: Smart cancellation based on timing, ignition position, and battery voltage
  • Power Efficiency: Designed for low current consumption
  • Voltage Range: Operates between 11VDC and 15VDC
  • Build Quality: Robust, high-quality components
  • Includes installation instructions
  • Note: If you want to replace the seal for the stock H-D turn signal module connector, it is available as 709107

Integrates with the OEM safety switches to prevent starting in gear without the clutch pulled.

Fits: 07-10 Softail; 07-11 Dyna; 07-17 V-Rod (NU)
