Modul blinkers Custom Dynamics Softail 01-06, Dyna 04-06

4 750 kr

Blinkersmodul med automatisk avstängning från Custom Dynamics
Läs mer

20500554 Custom Dynamics
  • Plug-and-play-ersättning för original TSM, TSSM och HFSM på Harley-Davidson
  • Fungerar endast som TSM – ersätter inte fabrikslarm eller säkerhetsfunktioner
  • Kompatibel med både LED och glödlampor (0,24 A–6 A maximal belastning per sida)
  • Kräver ingen lastutjämnare blinkers vid konvertering till Custom Dynamics LED-blinkers
  • Både manuell och automatisk avstängning baserad på tid och hojens nedläggningsvinkel
  • Stänger av automatiskt om motorcykeln lutar mer än 45° åt höger eller vänster i 1 sekund eller längre
  • Full funktion för varningsblinkers med smart avstängning baserad på tid, tändningsläge och batterispänning
  • Inbyggt kortslutnings- och överbelastningsskydd samt driftspänning på 11 VDC till 15 VDC

För TSSM-ersättning krävs TechnoResearch-diagnosverktyg för att slutföra parningsproceduren, men manuell parning är möjlig på vissa modeller. Kompatibel med CanDo och TechnoResearch-mjukvara. Monteringsanvisning ingår, och tätningspackning till originalkontakten säljs separat (art.nr 709107).

Passar: Softail 01-06, Dyna 04-06

OEM-nr: 68921-01, 68923-00, 68925-00

Turn Signal Module

  • Direct OEM TSM, TSSM, and HFSM Plug-and-Play replacement on Harley-Davidson models. Functions as TSM only, no security functions
  • Compatible with LED or incandescent bulbs (0.24 A-6 A maximum turn signal load per side), eliminating the need for a load equalizer or signal stabilizer when converting to Custom Dynamics’ LED turn signals
  • Simplified marrying procedure for select models and compatible with CanDo and Technoresearch software
  • Offers both manual and self-canceling turn signal cancelation functions based on timing and bank angle of the motorcycle; along with full operation of four-way hazards
  • Provides automatic shut off parameters when vehicle tilt exceeds 45° right or left for 1 second or more.
  • Low current consumption with built-in short circuit & over circuit protection
  • Wide operating voltage: 11 VDC to 15 VDC
  • This will replace OEM TSM (Turn Signal Module) 68921-01, TSSM (Turn Signal Security Module) 68923-00 (for US models) and TSSM 68925-00 (for HDI/EU models) It will not replace the TSSM factory alarm features
  • Models It requires the use of a TechnoResearch diagnostic tool to complete the TSSM module replacement procedure
  • For some models a manual procedure to marry the module to the bike is possible, for all others the TechnoResearch diagnostic tool is required for TSSM module replacement
  • Installation instructions are included
  • Lighting Compatibility: Works with both LED and incandescent bulbs
  • Turn Signal Load Range: Supports 0.24A to 6A per side
  • Four-Way Hazard Operation: Smart cancellation based on timing, ignition position, and battery voltage
  • Power Efficiency: Designed for low current consumption
  • Voltage Range: Operates between 11VDC and 15VDC
  • Build Quality: Robust, high-quality components
  • Includes installation instructions
  • Note: If you want to replace the seal for the stock H-D turn signal module connector, it is available as 709107

Fits: 01-06 Softail; 04-06 Dyna (NU)
