Ventilstyrning Kibblewhite Shouldered Manganese Intake 010 brons H-D 83-04

220 kr

Ventilstyrning i manganbrons för insugsventil från Kibblewhite
Läs mer

09262306 Kibblewhite
  • För insugsventil med +.010" överstorlek
  • Tillverkad i precisionsbearbetad manganbrons
  • Snabb värmeavledning och god smörjförmåga
  • Kragad kant (shoulder) ger ett fast stopp för enkel montering
  • Kortad för att klara ventillyft på upp till .600" / 0.600"
  • Brotschas enkelt till rätt mått med borrmaskin och henas med kulhenare
  • Tillverkad i USA

Används tillsammans med ventiltätningar i OEM-stil på 0.420". Mjukare än C630-lagerbrons men enklare att brotscha till rätt dimension.

Passar: H-D 83-04

Material Bronze
Produkt-typ Valve Guide
Storlek Oversize (+0,010 tum)
Tillverkarens Art. Nr. 20-2129M

Shouldered Manganese Bronze Valve Guide

  • Precision-machined
  • Guides can be easily reamed with a battery-operated or electric drill and finished with a high-quality ball hone
  • Shouldered for a positive stop for easy installation and best performance
  • Made in the USA
  • KPMI, intake valve guide. Manganese. +.010"
  • Comes with special shoulder for ease of installation
  • Shortened to accept valve lifts up to .600"
  • Softer and less durable then C630 bearing bronze but will allow a lower cost and reaming to size is quick and easy
  • Finish can be done with simple tools like a ball hone and an electric drill
  • Rapid heat transfer and excellent lubricity
  • Note: Special Manganese reamers & hones are available
  • Note: Standard non-oversize dimensions (for reference only) are 0.5620" O.D. (14.27mm); .3085" I.D. (7.84mm); 2.100" OAL (53.34mm)

Accepts up to 0.600" lift cams. Use OEM style 0.420" valve seals.

Fits: 84-99 Evo Big Twin; 99-04 Twin Cam; 86-03 XL Sportster (NU)
