Gänglära MIB Whitworth 4-62
Gängtolk för Whitworth-gängor
Läs mer
- Används för säker identifiering av gängtyp och gängstigning på bultar och muttrar
- För Whitworth-gängor (BSW, British Standard Whitworth)
- Gängvinkel: 55 grader
- Antal blad: 28
- Gängstigning: 4, 4.5, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 16, 18, 19, 20, 22, 24, 25, 26, 28, 30, 32, 36, 40, 48, 60, 62
Whitworth-gängor förekommer på många äldre brittiska motorcyklar och bilar tillverkade före 1970.
| Produkt-typ | Workshop misc |
| Kategori | Workshop misc |
Bolt thread pitch gauge. Whitworth threads 4-62
- Used for a positive identification of the type and pitch (windings) of threads used on bolts or nuts
- Whitworth threads (BSW, Britisch Standard Whitworth) is an imperial standard developed in 1841 and became the British Standard
- Today you may find this thread on many older (but not all) pre-1970 British motorcycles and cars
- Degree: 55 degrees
- Number of blades: 28
- Pitch: 4, 4.5, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 16, 18, 19, 20, 22, 24, 25, 26, 28, 30, 32, 36, 40, 48, 60, 62
