Gaffelpatron fram Öhlins NIX22 FLTRXSE 14-16
Öhlins NIX 22 gaffelpatronsats fram
Läs mer
- Öhlins NIX-teknik med kompression i vänster ben och returdämpning i höger ben
- 22 mm kolvdiameter, kompatibel med konventionella framgafflar
- Extern justering av kompression, retur och förspänning i topplocket
- Slaglängd: 4.567"
- Viktintervall förare: min 150 lb – max 350 lb
- 1" (25 mm) sänkningssats ingår
- Rekommenderad oljenivå: 140 mm (R&T #5, ca SAE 7.5W)
- ABE-godkänd, levereras i par
Monteras direkt i originalgaffeln. Fjädrar ingår inte och beställs separat (fjäderserie 08790-xx) baserat på förarens vikt och preferenser. Innehåller inte uppdragsverktyg (pullup tool) eller stoppbleck.
Passar: FLTRXSE 14-16
OEM-nr: 08866-04
| Produkt-typ | Fork springs |
| Kategori | Fork springs |
Fork Cartridge Kit
- Öhlins NIX Technology
- External Compression and rebound adjustment
- External preload adjustment
- 1" lowering kit included
- 22 mm piston diameter
- Öhlins setting bank
- Piston diameter: 22mm
- Position: front
- Spring series: 08790-xx (order separately)
- Lowering spring set: 963141 (08866-04) 25mm lowering spring set
- Recommended oil: 962112 (1 liter) or 962113 (4 liter) R&T #5 (approx SAE 7.5W)
- Oil level mm: 140
- Packaging unit: pair
- ABE approved
- Note: Springs are not included and must be ordered separately
- Please follow Öhlins recommendations regarding spring rates and oil in relation to rider's weight and preference as listed
- Description: The Öhlins NIX 22 cartridge kit comes with 22mm pistons, which makes it compatible with motorcycles that are equipped with conventional (non-upside down) front forks
- The proven 'NIX' design is derived from the technology that helpt provide championships on the highest level and each NIX 22 cartridge kit is made to fit the specific bike series to meet the requirements and characteristics of that bike
- It features compression damping in the left leg and rebound damping in the right leg, allowing more precision, stability and feedback for improved rider confidence
- All adjustments, including spring preload, are made at the top cap
- It is a bolt-in installation into the original front fork, but springs must be ordered separately the match the rider's weight and preferences for the perfect set-up
Does not include pullup tool or stopper plate. Spring rates included: 12 n/m and 13 n/m Stroke length: 4.567" Weight range (Based on rider only because it’s a front cartridge kit) – Min 150 lb – Max 350 lb
Fits: 14-16 FLTRXSE; 14-16 FLTRXS; 14-16 FLTRUSE; 14-16 FLTRU; 14-16 FLHXSE; 14-16 FLHX (S); 14-16 FLHTCU
