Spegel glaslös styrände Motogadget mo.view Blade 22mm och 1" styre

1 780 kr

Styrändsbackspegel i glaslös aluminiumdesign från Motogadget
Läs mer

573675 MotoGadget
  • Patenterad glaslös spegelyta bearbetad direkt ur stommens aluminium
  • CNC-fräst ur enfärgad aluminium och anodiserad med skruvar i rostfritt stål
  • Mått spegelkropp: 100 mm bredd, 60 mm höjd och 4 mm tjocklek (utan kulled)
  • Spegelyta ca 37,5 cm² samt 61 mm lång spegelarm
  • Klämdiameter för 22 mm och 1" styren med 8 mm klämbredd
  • Vikt: 94 g
  • Kan monteras över eller under styret på både höger och vänster sida
  • Levereras med 1x spegel med arm, 1x styrklammer och QR-kod för monteringsanvisning

Ej ECE-godkänd och inte godkänd för allmän väg inom EU (endast för showbruk). Monteras direkt på styret eller med styrändsadaptrar (575353 eller 575352, säljs separat) om reglage inte kan flyttas. Kompatibel med Motogadget styrände-blinkers, mo-grip samt knappstyrningarna mo-switch och mo-switch mini.

Passar: för 22 mm och 1 tums styre

mo.view Blade Handlebar End Mirror

  • The small and reduced handlebar end mo.view Blade mirror can be mounted above or below the handlebars. The angle of the mirror arm can be individually selected.
  • Our glassless mirror series mo.view is unique in the world. The special feature of our mirrors is the patented mirror surface, which is worked directly from the metal of the body. The aluminium itself is the mirror surface.
  • The mirror body itself becomes very thin and light, creating a weightless design with no rim or frame. The convex mirror surface is manufactured by fly cutting using diamond tools on ultra-precision machines in Berlin. It is then made resistant to oxidation, corrosion and abrasion by a complex plasma coating in a vacuum.
  • The mirror body, mirror arm and the clamp for the handlebar end are milled on CNC machines from the solid aluminium and anodized high quality. All screws are made of stainless steel. The precise ball joint allows the comfortable and very stable adjustment of the mirror. Glass breakage or fallen out glasses are simply not possible.
  • The handlebar end mirror can be mounted above or below the handlebar. The small arm can be swivelled. The mirror is suitable for the right and left side. Mounting is directly on the handlebar end (22 mm and 1 inch) or if the grips and fittings can not be moved, using the mo.view bar adapter.
  • Mirror body width: 100 mm.
  • Mirror body height: 60 mm.
  • Thickness of the mirror body without ball head: 4 mm.
  • Length of the mirror arm: 61 mm.
  • Mirror surface: approx. 37.5cm².
  • Clamp diameter: can be used for 22 mm and 1 inch handlebars.
  • Clamp width: 8 mm.
  • Weight: 94 g.
  • Scope of delivery: 1x mo.view blade mirror (without ECE marking) with arm, 1x clamp & QR code for mounting and operating instructions.
  • Warning: This mirror is not approved for use on public roads within the EU.
  • Aluminium.
  • Not ECE approved, for show use only; aluminum; oval, width 100mm, height 60mm; stem 61mm
  • CNC machined from aluminum and finish-anodized, but a regular glass lens is not used
  • Note: Installation compatible with Motogadget bar end turn signals, the mo-grip and the push button controls mo-switch and mo-switch mini
  • Note: Mirror comes with handlebar clamp but optional bar-end adapters (575353 clamp-on or 575352 clamp-in) are available and sold separately

Fits: for 22mm and 1 inch handlebar
