Spegel Motogadget Club 60" svart for 22mm and 1 inch handlebar
Styrändsbackspegel i glaslöst aluminium från Motogadget
Läs mer
- Glaslös spegel där den konvexa metallytan i aluminium fungerar direkt som spegel
- CNC-fräst ur massivt aluminium med högkvalitativ anodisering
- Bredd: 114 mm, höjd: 80 mm, tjocklek utan kulled: 4,5 mm
- Stam, längd: 60 mm (spegelarm 72 mm)
- Klämdiameter: passar styren på 22 mm och 1 tum (klämbredd 10 mm)
- Rostfria skruvar och stabil justering med exakt kulled
- ECE-godkänd och väger 125 g
- Levereras styckvis med arm, klämma och manual
Kan monteras ovanför eller under styret på både höger och vänster sida. Kompatibel med Motogadget styrände-blinkers, mo.grip samt reglagen mo.switch och mo.switch mini. Styrklammer ingår, men alternativa styrändsadaptrar (575353 eller 575352) finns och säljs separat.
Passar: för 22 mm och 1 tums styre
mo.view Club 60 mm Handlebar End Mirror
- The handlebar end mirror can be mounted above or below the handlebar. The angle of the mirror arm is individually selectable.
- Our glassless mirror series mo.view is unique in the world. The special feature of our mirrors is the patented mirror surface, which is worked directly from the metal of the body. The aluminium itself is the mirror surface.
- The mirror body itself becomes very thin and light, creating a weightless design with no rim or frame. The convex mirror surface is manufactured by flycutting using diamond tools on ultra-precision machines in Berlin. It is then made resistant to oxidation, corrosion and abrasion by a complex plasma coating in a vacuum.
- The mirror body, mirror arm and the clamp for the handlebar end are milled from solid aluminium on CNC-machined from solid aluminium and anodized to a high quality.
- All screws are made of stainless steel.
- The precise ball joint allows the mirror to be adjusted comfortably and very stably. Glass breakage or glass falling out is simply not possible.
- Mirror body width: 114 mm.
- Mirror body height: 80 mm.
- Thickness of the mirror body without ball head: 4.5 mm.
- Length of the mirror arm: 72 mm.
- Clamp diameter: can be used for 22 mm and 1 inch handlebars.
- Clamp width: 10 mm.
- Weight: 125 g.
- Scope of delivery: 1x rear-view mirror mo.view club 60 (with ECE marking) with arm, 1x clamp & instructions manual.
- ECE approved; handlebar end mirror; aluminum; 114mm wide x 80mm high; Stem length 60mm
- CNC machined from aluminum and finish-anodized, but a regular glass lens is not used
- Left & right side compatible, except where noted, allows above or below bar end installation and mounts directly onto or into 22mm or 1" diameter handlebars
- Body thickness approx
- Note: Installation compatible with Motogadget bar end turn signals, the mo.grip and the push button controls mo.switch and mo.switch mini
- Note: Mirror comes with handlebar clamp but optional bar-end adapters (575353 clamp-on or 575352 clamp-in) are available and sold separately
Fits: for 22mm and 1 inch handlebar
