Strömbrytare Motogadget Mo-Switch Mini 3 knappar svart hus rostfria knappar 22 mm
Kompakt tryckknappskontroll i CNC-fräst aluminium från Motogadget
Läs mer
- Tillverkad i CNC-fräst billet-aluminium med hög kvalitet
- Passar styren med 22 mm (7/8") diameter (finns även för 1")
- Innehåller 3 återfjädrande miniatyrströmbrytare och 2 meter kabel
- Vibrations- och stänkvattenskyddad enligt IP65
- Monteras med två försänkta M5-skruvar
- Mått: 45 mm ytterdiameter x 14 mm bredd
- Två enheter kan monteras mittemot varandra för totalt 6 strömbrytare utan att bygga mer än ett vanligt kontakthus
Konstruerad för att användas tillsammans med reläer.
Passar: 22mm
| Produkt-typ | Switch |
| Färg | Black- Polished- Stainless Steel |
| Tillverkarens Art. Nr. | 4000346 |
-
Hämtamo.switch_mini_Instructions.pdf170.07 KB
mo-SWITCH MINI
- High quality universal push-button control for handle bars with 1 in. or 22 mm (7/8 in.)
- The casing is made from CNC machined billet aluminium and available in mirror polished or black finished surface respectively.
- Vibration- and spraywater-proof (IP65).
- Mounted on handlebars
- Fits 22mm (7/8") diameter handlebars
- Includes 3 momentary truly miniature push-button switches and 2 meter wiring
- Installs with two M5 screws that are flush mounted
- When installing two of these switches opposite to each other you will have 6 switches of which the housings together are still not larger than a regular a regular switch housing
- Dimensions: 45mm OD x 14mm wide
- Note: Designed for use with relays
Fits: 22mm (7/8") diameter handlebars
