Strömbrytare Motogadget Basic silver 4004011

1 190 kr

Styrknappsats från Motogadget för 1" eller 22 mm (7/8") styren
Läs mer

06160379 MotoGadget
  • Universell tryckknappskontroll för styren med 1 tum eller 22 mm (7/8 tum) diameter
  • CNC-fräst hus i billet-aluminium med blanksvart anodisering
  • Utrustad med två eller tre svarta knappar riktade mot föraren
  • Vibrations- och stänkvattenskyddade knappar enligt IP65
  • Ergonomisk tryckpunkt med lätt mekanisk spärr för säker användning med handskar
  • Möjlighet till en- eller tvåtrådsanslutning med intern jordanslutning
  • Dold M4 rostfri fästskruv ger säker montering
  • Kompatibel med vanliga styrenheter som mo.unit blue/basic

Kombineras med en elektronisk styrenhet (ingår ej) för att styra exempelvis belysning, blinkers, elstart och tuta. Vid eventuell skada finns knapparna tillgängliga separat och kan bytas ut.

Produkt-typ Switch
  • mo.switch_basic_Instructions.pdf
    1.22 MB
    Hämta

Mo.Switch Basic

  • The mo.switch basic is a universal, high-quality push-button control for handlebars with 1 inch or 22 mm (7/8 inch) tube diameter in a simple, elegant design. In combination with an electronic push-button control box (not included), these CNC-made push-buttons can switch all electrical units such as lights, indicators, electric starters, horn and much more.
  • CNC-milled from billet aluminium the housing is anodised in glossy black. Optionally, the button holder (inlay) is also available with a silver anodized color. The compact housing is equipped with either two or three push buttons. All buttons are always in direction to the driver.
  • The two or three buttons per unit are always black. A hidden M4 stainless steel mounting screw clamps the housing securely to each handlebar.
  • The individual buttons are of high quality, very robust and protected against vibrations and splash water (IP65).
  • Due to sufficient size and ergonomic pressure point (light, mechanical detent), they allow a safe operation - even when operating with a glove.
  • A single-wire or two-wire wiring is easily possible by two terminals per push-button. One terminal for ground is already provided internally for single-wire wiring. Cable routing in the handlebars is therefore easy.
  • In case of possible damage, the single push-buttons are available individually and can be replaced.
  • The mo.switch basic is of course compatible with all common push button controls such as the mo.unit blue/basic.
