Styrmodul positionsljus Axel Joost Elektronik Marker light X

730 kr

Styrmodul för automatisk avstängning av positionsljus
Läs mer

954147 Elektronik Box
  • Släcker automatiskt positionsljus eller DRL vid blinkning för ökad synlighet
  • Kan även användas för att koppla bort positionsljusfunktionen i blinkers
  • Mycket kompakt format som ryms i de flesta styren
  • Hus i ABS ingjutet med vattentät 2K-epoxiharts
  • Mått: 38 mm x 16 mm x 11 mm
  • Spänningsintervall: 7–18 V
  • Anslutningar: ingångar 0,14 mm², utgångar 0,75 mm²
  • Maximal ström: 5 A per utgång (max omgivningstemperatur 80 °C)

Modulen är framtagen av Axel Joost Elektronik och kan monteras nästan var som helst tack vare sin kompakta storlek.

Kategori Marker lights
Produkt-typ Marker lights

Axel Joost Elektronik, Marker light X

  • This module is used to automatically switch off a light, like a marker light or turn signal daylight running light (DRL), for better visibility of the turn signal during daytime
  • The module is very small and can be installed almost anywhere, including inside most handlebars
  • The module can also be used to cancel the marker/running light function of the turn signals
  • Dimensions: 38 mm x 16 mm x 11 mm
  • Body material: ABS with waterproof poured 2k epoxy resin
  • Input voltage range: 7
  • 18 Volt
  • Connections: Inputs 0.14 mm², Outputs 0.75 qmm
  • Maximum current: 5 Ampere per output
  • Maximum ambient temperature: 80 degree Celsius
