Modul Elektronikbox Axel Joost Elektronik Minimal

640 kr

Axel Joost Elektronik Minimal Indicator modul
Läs mer

954152 Elektronik Box
  • Förenklar instrumenteringen för ett renare utseende
  • Kan monteras inuti strålkastaren eller styret
  • Driver en 3-färgs LED som visar blinkers, helljus, neutral eller oljetryck
  • Visar upp till 4 indikeringar samtidigt i rött, grönt, blått eller orange
  • Visar även 2 eller 3 signaler samtidigt
  • Hus i ABS ingjuten med vattentät 2K-epoxiharts
  • Mått: 38 mm x 16 mm x 11 mm
  • Ingångsspänning: 7–18 V, anslutningar: 0,14 mm², 20 cm, max omgivningstemperatur: 80 °C
Kategori Indicator lights led
Produkt-typ Indicator lights led

Axel Joost Elektronik, Minimal Indicator module

  • This module can help simplify your dash for a much cleaner look
  • This small module (installs inside headlamp or even inside the handlebar) can power a 3-color LED to show turn signal, high beam, neutral or oil pressure LED indicators
  • Up to 4 indicators can be clearly displayed at the same time on a single 3-color LED showing Red, green, blue or orange
  • Even 2 or 3 signals can be shown simultaneously
  • Dimensions: 38 mm x 16 mm x 11 mm
  • Body material: ABS with waterproof poured 2k epoxy resin
  • Input voltage range: 7
  • 18 Volt
  • Connections: 0.14 mm², 20 cm
  • Maximum ambient temperature: 80 degree Celsius
